| Product |
 |
 |
 |
| Processor (CPU) |
AMD Embedded Ryzen R2314 (4 Core /4 Threads) @ 3.5GHz
AMD Embedded Ryzen R2514 (4 Core /8 Thread) @ 3.7GHz
Intel i3 1215U (2 Performance Cores @ 4.4GHz + 4 Efficient Cores @ 3.3GHz / 8 Threads) |
Intel Twin Lake-N 64-bit N150 (13th Generation)
up to 3.6 GHz, 4 Core / 4 Thread |
| Processor (CPU) Specs |
AMD: AMD-V (SVM) virtualization support. AMD-Vi (IOMMU) device passthrough. AMD Secure Processor (PSP) hardware security, Secure Boot support, Memory Guard support (platform dependent), integrated Radeon Vega graphics.Intel: Intel Speed Shift Technology. Intel VT-x and VT-d virtualization support. Intel Control-Flow Enforcement Technology (CET), Intel Total Memory Encryption (TME), Intel Boot Guard, Intel Secure Key (DRNG), Intel Gaussian & Neural Accelerator (GNA). |
Intel SpeedStep Technology. Intel VT-x and VT-d virtualization support. Intel Control-Flow Enforcement Technology (CET), Intel Total Memory Encryption (TME), Intel Boot Guard, Intel Secure Key (DRNG) |
| Memory |
No RAM, 8GB, 16GB or 32GB DDR4 260pin Notebook (SO-DIMM) - Upgradeable |
8GB or 16GB DDR4 260pin Notebook (SO-DIMM) - Upgradeable |
8GB or 16GB LPDDR5 Integrated |
| Max. Supported Memory |
Max. 64GB DDR4
Two Slots |
Max. 32GB DDR4
One Slot |
Integrated |
| Storage |
256GB or 512GB M.2 SSD SATA 2280 NGFF |
256GB or 512GB M.2 SSD SATA 2280 NGFF |
256GB or 512GB M.2 SSD SATA 2242 NGFF |
| Storage Interface |
2x M2 2280 NVMe-enabled |
2x M2 2280 NVMe-enabled |
1x M2 2242 NVMe-enabled |
| Max. Supported Storage |
Max. 2 x 4TB NVMe or 1x4TB SATA + 1x 4TB NVMe |
Max. 2 x 2TB NVMe or 1x2TB SATA + 1x 2TB NVMe |
Max. 1TB SATA/NVMe |
| Ethernet |
1x Realtek 8111H 10/100/1000Mbps |
2x Intel 2.5Gbps i226-V |
2x Realtek 8111H 10/100/1000Mbps |
| Audio |
Integrated Realtek Audio with Single 3.5mm Jack for Audio Out and Microphone |
| Graphics |
AMD: AMD Radeon Vega 8 Graphics. API Support: DirectX 12, OpenGL 4.6, Vulkan 1.2
Intel: Intel UHD Graphics (12th Gen). API Support: DirectX 12.1, OpenGL 4.6, Vulkan 1.3
Supports up to three 4K displays at 60Hz. |
Intel 13th Gen Ultra HD Graphics. Supports three 4K displays at 60Hz. API Support: DirectX 12, OpenGL 4.6, Vulkan 1.3 |
| Display |
1x Display Port
1x HDMI
1x USB-C (Display Port) |
1x Display Port
1x HDMI
1x USB-C (Display Port) |
3x HDMI 2.1 |
| USB Ports |
6x USB 3.2
1x USB-C (with Display Port) |
2x USB 3.0
2x USB 2.0
1x USB-C (with Display Port) |
3x USB 3.1 |
| Wireless Connectivity |
Realtek WiFi 6 (AX) & Bluetooth 5.2 PCI-E
Upgradeable to 6E+BT5.3 or WiFi7+BT 5.4 |
Intel 3165NGW WiFi 5 (AC) & Bluetooth 4.2 PCI-E
Upgradeable to WiFi 6+BT5.2, WiFi 6E+BT5.3 or WiFi7+BT 5.4 |
Realtek WiFi 6 (AX) & Bluetooth 5.2 PCI-E
Upgradeable to 6E+BT5.3 or WiFi7+BT 5.4 |
| Other Features |
Ultra-silent design, TPM 2.0 Support, Secure Boot, Kensington Lock Port |
Ultra-silent design, TF (SD) Card Reader, TPM 2.0 Support, Secure Boot, Kensington Lock Port |
Ultra-silent design, TPM 2.0 Support, Secure Boot, Kensington Lock Port |
|
| Max. Power Consumption |
65W / 19V DC |
36W / 12V DC |
30W / 12V DC |
| Dimensions |
5.0" x 5.0" x 1.7" |
5.0" x 5.0" x 1.7" |
3.5" x 3.5" x 1.7" |
|
| Operating System |
- Clean - No Operating System
- Home Assistant
- Zorin OS Core
- Proxmox V.E.
- FreePBX 17
- Microsoft Windows 11 Pro (OEM) - SKU FQC-10529
- Pulcro.io Recovery System included (on separate partition than the Operating System)
|
|
| Warranty |
|
| Included Accessories |
- 100-240V / 50-60 Hz AC Adapter with US Plug
- 75mm & 100mm VESA Monitor Mounting Kit (incl. Screws)
- 3 ft Ethernet Cable
- User's Manual & Warranty Information
|
|
|
|
|
|
