| TurnKey Node | TurnKey Two | TurnKey QBE | |
|---|---|---|---|
| Product |  |
 |
 |
| Processor (CPU) | AMD Embedded Ryzen R2314 (4 Core /4 Threads) @ 3.5GHzAMD Embedded Ryzen R2514 (4 Core /8 Thread) @ 3.7GHz
Intel i3 1215U (2 Performance Cores @ 4.4GHz + 4 Efficient Cores @ 3.3GHz / 8 Threads) |
Intel Twin Lake-N 64-bit N150 (13th Generation) up to 3.6 GHz, 4 Core / 4 Thread |
|
| Processor (CPU) Specs | AMD: AMD-V (SVM) virtualization support. AMD-Vi (IOMMU) device passthrough. AMD Secure Processor (PSP) hardware security, Secure Boot support, Memory Guard support (platform dependent), integrated Radeon Vega graphics.Intel: Intel Speed Shift Technology. Intel VT-x and VT-d virtualization support. Intel Control-Flow Enforcement Technology (CET), Intel Total Memory Encryption (TME), Intel Boot Guard, Intel Secure Key (DRNG), Intel Gaussian & Neural Accelerator (GNA). | Intel SpeedStep Technology. Intel VT-x and VT-d virtualization support. Intel Control-Flow Enforcement Technology (CET), Intel Total Memory Encryption (TME), Intel Boot Guard, Intel Secure Key (DRNG) | |
| Memory | No RAM, 8GB, 16GB or 32GB DDR4 260pin Notebook (SO-DIMM) – Upgradeable | 8GB or 16GB DDR4 260pin Notebook (SO-DIMM) – Upgradeable | 8GB or 16GB LPDDR5 Integrated |
| Max. Supported Memory | Max. 64GB DDR4 Two Slots |
Max. 32GB DDR4 One Slot |
Integrated |
| Storage | 256GB or 512GB M.2 SSD SATA 2280 NGFF | 256GB or 512GB M.2 SSD SATA 2280 NGFF | 256GB or 512GB M.2 SSD SATA 2242 NGFF |
| Storage Interface | 2x M2 2280 NVMe-enabled | 2x M2 2280 NVMe-enabled | 1x M2 2242 NVMe-enabled |
| Max. Supported Storage | Max. 2 x 4TB NVMe or 1x4TB SATA + 1x 4TB NVMe | Max. 2 x 2TB NVMe or 1x2TB SATA + 1x 2TB NVMe | Max. 1TB SATA/NVMe |
| Ethernet | 1x Realtek 8111H 10/100/1000Mbps | 2x Intel 2.5Gbps i226-V | 2x Realtek 8111H 10/100/1000Mbps |
| Audio | Integrated Realtek Audio with Single 3.5mm Jack for Audio Out and Microphone | ||
| Graphics | AMD: AMD Radeon Vega 8 Graphics. API Support: DirectX 12, OpenGL 4.6, Vulkan 1.2 Intel: Intel UHD Graphics (12th Gen). API Support: DirectX 12.1, OpenGL 4.6, Vulkan 1.3 Supports up to three 4K displays at 60Hz. |
Intel 13th Gen Ultra HD Graphics. Supports three 4K displays at 60Hz. API Support: DirectX 12, OpenGL 4.6, Vulkan 1.3 | |
| Display | 1x Display Port 1x HDMI 1x USB-C (Display Port) |
1x Display Port 1x HDMI 1x USB-C (Display Port) |
3x HDMI 2.1 |
| USB Ports | 6x USB 3.2 1x USB-C (with Display Port) |
2x USB 3.0 2x USB 2.0 1x USB-C (with Display Port) |
3x USB 3.1 |
| Wireless Connectivity | Realtek WiFi 6 (AX) & Bluetooth 5.2 PCI-E Upgradeable to 6E+BT5.3 or WiFi7+BT 5.4 |
Intel 3165NGW WiFi 5 (AC) & Bluetooth 4.2 PCI-E Upgradeable to WiFi 6+BT5.2, WiFi 6E+BT5.3 or WiFi7+BT 5.4 |
Realtek WiFi 6 (AX) & Bluetooth 5.2 PCI-E Upgradeable to 6E+BT5.3 or WiFi7+BT 5.4 |
| Other Features | Ultra-silent design, TPM 2.0 Support, Secure Boot, Kensington Lock Port | Ultra-silent design, TF (SD) Card Reader, TPM 2.0 Support, Secure Boot, Kensington Lock Port | Ultra-silent design, TPM 2.0 Support, Secure Boot, Kensington Lock Port |
| Max. Power Consumption | 65W / 19V DC | 36W / 12V DC | 30W / 12V DC |
| Dimensions | 5.0″ x 5.0″ x 1.7″ | 5.0″ x 5.0″ x 1.7″ | 3.5″ x 3.5″ x 1.7″ |
| Operating System |
|
||
| Warranty |
|
||
| Included Accessories |
|
||
| Price | TurnKey Node
|
TurnKey Two
|
TurnKey QBE
|
